Circular Centrifugal Fan - OCD

Airflow Range: 0~1,750 m³/h (0~1,029 CFM)

Static Pressure Range: 40~700 Pa (0.16~2.81 in.WG.)

Drive Configurations: Direct

Installation Methods: Duct

Applications: Low airflow/ Offices/ Conference room air processing

For reference only. Please contact our sales rep for detailed performance fan curve. Thank you.

CFD flow field pressure and rate of INFINAIR patented complete mixed flow fan (process illustration)

 CFD flow field trace of a certain new box-type centrifugal fan of INFINAIR (process illustration)

 CFD analysis for inducing fan of garage (process illustration)

2. With respect to garage ventilation system optimization, INFINAIR has successfully developed a new, complete series centrifugal inducing fan with high static pressure as wehll as far projection distance, and guide the ventilation system layout of underground garage of customer. The following is the flow field layout simulation of an underground garage.

INFINAIR has mature FEA technical capability
1.In the practice process of FEA technology for many years, INFINAIR has accumulated a large number of data and experience which are suitable for actual physical property of common materials in China market.
2.INFINAIR Research Institute fully calculates and repeatedly adjusts the material type, material thickness, structural form and processing way in design stage to ensure that the parts can resist various pressures in operation, ensure that the fan can operate reliably for a long time, and ensure that the product cost is reasonable.
3.The final product scheme goes through the reliability verification of INFINAIR laboratory, conducts failure analysis and life extension analysis for products suffered aging test, reaches a definite conclusion, and thus reasonably saves equipment investment while improving product reliability.



CFD flow field pressure cloud of a certain centrifugal fan of INFINAIR (process illustration)

 ——Numerical simulation technology CAE
1.Numerical simulation is a kind of application of Computer Aided Engineering (CAE), mainly includes two core technologies of CFD and FEA.
2.CFD is short for Computational Fluid Dynamics. CFD simulate-calculates the product performance inside computer, provides guidance for aerodynamic model design (optimize the number of blades, angles and widths) and noise prediction of fan, especially impeller, and thus helps the designer basically predict the final aerodynamic performance without producing so many prototypes, consequently realizes quick customized design or systemic optimization.
3.As a “virtual laboratory”, CFD can realize fast iteration, save cost and reduce R&D period, is a strong tool for effective and reliable fan R&D and non-standard customization, and will provide accurate scheme for optimization of ventilation system.

 Process illustration of FEA stress distribution for customized centrifugal fan impeller made by INFINAIR

Successful cases of INFINAIR FEA technology:
1.The following is process illustration for a customized fan analyzed by INFINAIR Research Institute . According to the system natural vibration characteristics of the customer, INFINAIR Research Institute makes vibration mode analysis for the overall customized fan, achieves structural optimization, avoids resonating with system, and ensures that the fan can operate reliably for a long time.

 Modal analysis for fan frame made by INFINAIR Research Institute through FEA

2.In order to analyze the bearing and deformation of motor platform in operating process, INFINAIR Research Institute conducts modal analysis based on FEA technology.

 R&D and Innovation: R&D team


INFINAIR Research Institute focuses on “product life cycle” and is fully responsible for management of all products. The responsibilities are as follows:
1.Fundamental research of hydromechanics;
2.Market research of ventilation, gas heating, motor, air purification and automatic control of ventilation system;
3.Product planning, R&D and manufacturing;
4.Customization;
5.Market launch and promotion, maintenance and update/obsolescence;
6.Product experiment and test, product certification;
7.Order processing and technical support.

As a new high-tech enterprise in Shanghai, INFINAIR Research Institute has an excellent technical talent team combing elder, middle-aged and young people and an effective talent cultivating mechanism. Immersing in Youth Culture of Ready to learn, Hard-working, Enterprising, Forward-looking, Innovative, Pioneering for a long time, INFINAIR R&D team has cultivated innovative spirit which has become source for core competitiveness of company.

INFINAIR Research Institute always takes Reliable, Convenient, Novel as the basic concept of product R&D and design. Under the guidance of the spirit and concept, the institute has reached innumerable great achievements, obtained more than 40 patent certificates and won many honors, it has launched many products for the first time in industry, what is more important is that INFINAIR Research Institute takes “at customers’ side” and resolving practical product issues for customer as an important work habit, and thus creates valuable and satisfactory experience, gains full trust of customer. INFINAIR Research Institute will never stop innovating.

Production Capacity

Advanced Technology and Equipment Ensure Product Reliability

--Much to expect from just having excellent design and a precise detail-oriented drawing? In fact, there is still a long way to go before finalizing a reliable product that comes only from high processing precision and advanced technology.

-- INFINAIR has put to use a large number of high-precision CNC processing machines. Besides, INFINAIR has produced lots of special-purpose equipment and core molds through its independent R&D efforts.

--Also, R&D staff and production workers at INFINIAR are mobilized to promote technological improvements through concerted efforts. By analyzing onsite issues and sharing the actions for improvement, product reliability has been continuously enhanced with the help of wisdom of frontline workers.

Reliability Certified by Quality Control Systems

--INFINAIR has been awarded triple certification in ISO9001, ISO14001 and OHSAS18001 by SGS, a world famous certification agency.

--INFINAIR performs tests on key points at all stages of production and products must be rigorously tested before leaving the factory to ensure reliability. A case in point: INFINAIR made huge investments in building a vibration test bench on the production line and importing dedicated test equipment from Germany for greater accuracy. This bench covers 180 square meters with its foundation reaching 20 meters underground.

--Furthermore, INFINAIR works with consulting companies to launch 5S programs and take the Six Sigma approach to the continuous improvement of products. In this way, abilities of staff can be improved and a sustainable quality management system built.

The TÜV SÜD Certificate

 AMCA accredited lab



 AMCA membership certificate

 Numerous Product Patents

 CE Certification

 CNAS lab accreditation

 ATEX Certification

 ISO 9001 quality management system

 OHSAS 18001, Occupational Health and Safety Assessment Series





ISO 14001 environmental management system

 Explosion-Proof Certification

 Fire Fighting Certification

Case Study

Xinzheng Int’l Airport Phase 2

This video is about a signature airport job of INFINAIR ventilation. We participated and competed the bidding for this ventilation project - Xinzheng Airport in 2014.


The Construction and Operation of Nuclear Power Plant

With the lack of fossil fuel and aggravation of pollution, nuclear power is the unique new power can be Large-scale applied with great prospect.


INFINAIR fans for the KIA Yancheng Job

The Dongfeng Yueda KIA is an joint-venture of Dongfeng Motor Corporation、Jiangsu Yueda Investment Co. Ltd and Korean KIA Automatic Vehicle. Ltd, partly occupying respectively 25%、25%、50% of the company.
