Airflow range: 300 ~52000 m³/h （176～30588 CFM）

Static pressure range: 100 ~ 700Pa （0.4～2.8 CFM）

Drive type: Direct drive, Belt drive

Installation methods: Rooftop curb mounted

Application: Chinese and western fast food restaurant, Electronics, automobile industry welding fume exhaust, Laboratory exhaust, Odor or VOC contaminated air exhaust and explosion-proof exhaust

Airflow Range: 100 ~ 66,000 m³/h （59～38,824 CFM）

Static Pressure Range: 50～2,100 Pa （0.2～8.4 in.WG）

Drive Types: Direct drive

Mounting Types: Methods: Floor, Hanging, Duct mounted

Applications: Duct supply/exhaust,filter supply/exhaust,low noise cabinet,smoke removal

Certification: AMCA, TUV, CE, ATEX, CNEX, CCCF, EG

Airflow Range: 1,800～80,000 m³/h (1,059～47,059 CFM )

Static Pressure Range: 100～1,400 Pa (0.4～5.62 in.WG.)

Drive Configurations: Belt Drive

Applications: AHU fans, HVAC fans, air purifier fans and ventilation fans among others

Certification: AMCA

Airflow Range: 1,000～380,000 m³/h (588~223,529 CFM)

Static Pressure Range: 300～4,100 Pa (1.2~16.46 in.WG.)

Operating Temperature: -20～450 ℃

Drive Types: Direct/ Belt/ Coupling drive

Mounting Type: Base mounted

Applications: General air supply and exhaust/ Explosion-proof air supply and exhaust / Smoke removal

Certification: AMCA, ATEX, CNEX, CCCF, CE, EG

Airflow Range: 1,000～32,000 m³/h (588～18,824 CFM)

Static Pressure Range: 90～800 Pa (0.36～3.21 in.WG.)

Drive Configurations: Belt Drive

Applications: AHU fans, HVAC fans, air purifier fans and ventilation fans among others

Certification: AMCA

Airflow Range: 4,000～230,000 m³/h (2,353~135,294 CFM)

Total Pressure Range: 30～2,000 Pa (0.12~8.03 in.WG.)

Drive Type: Direct drive

Mounting Types: Base mounted/ Ceiling hung

Applications: General air supply and exhaust/ Explosion-proof air supply and exhaust / Positive pressure air supply/ Smoke removal

Certification: AMCA, TUV, CNEX, CCCF, EG

Airflow Range: 1,000～100,000 m³/h (588~58,824 CFM)

Static Pressure Range: 1,000～2,150 Pa (4~8.63 in.WG.)

Drive Types: Direct/ Belt drive

Mounting Types: Roof mounted / Base mounted / Ceiling hung

Applications: Ducted air supply and exhaust / Explosion-proof air supply and exhaust / Positive pressure air supply/ Smoke removal

Certification: AMCA, CCCF, CNEX, TUV, EG

Airflow Range: 300～52,000 m³/h (176～30,588 CFM)

Static Pressure Range: 100～700 Pa (0.4～2.81 in.WG.)

Drive Types: Direct/ Belt drive

Mounting Types: Rooftop

Applications: Rooftop ventilation / Explosion proof air supply and exhaust / Smoke removal

Certification: AMCA, TUV, CNEX, CCCF

Airflow Range: 500～56,000 m³/h (294～32,941CFM)

Static Pressure Range: 136～1,400 Pa (0.55～5.62 in.WG.)

Drive Type: Belt/ Direct drive

Mounting Types: Base Mount/ Ceiling Hung

Applications: Industrial ventilation / Explosion proof air exhaust / Kitchen fume exhaust

Certification: AMCA, CE, CNEX, EG

Airflow Range: 1,200～140,000 m³/h (706～82,353 CFM)

Static Pressure Range: 300～2,600 Pa (1.2～10.44 in.WG.)

Drive Configurations: Belt Drive

Applications: AHU fans, HVAC fans, air purifier fans and ventilation fans among others

Certification: AMCA

Airflow Range: 1,000 ~ 260,000 m³/h (588 ~ 152,941 CFM)

Total Pressure Range: 200 ~ 3,150 Pa (0.8 ~ 12.65 in.WG.)

Drive Types: Belt drive

Applications: AHU fans, HVAC fans, air purifier fans and ventilation fans among others

Certification: AMCA, EG

Airflow Range: 1,000 ~ 266,000 m³/h (588~156,471 CFM)

Total Pressure Range: 500 ~ 7,400 Pa (2.01~29.71 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Configurations: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certifications: AMCA, CNEX, ATEX, CE, EG
