Airflow Range: 1,000～380,000 m³/h (588~223,529 CFM)

Static Pressure Range: 300～4,100 Pa (1.2~16.46 in.WG.)

Operating Temperature: -20～450 ℃

Drive Types: Direct/ Belt/ Coupling drive

Mounting Type: Base mounted

Applications: General air supply and exhaust/ Explosion-proof air supply and exhaust / Smoke removal

Certification: AMCA, ATEX, CNEX, CCCF, CE, EG

Airflow Range: 1,000 ~ 220,000 m³/h (588 ~ 129,412 CFM)

Total Pressure Range: 300 ~ 5,400 Pa (1.2 ~ 21.68 in.WG.)

Operating Temperature: -20～450 ℃

Drive Type: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certification: CE, ATEX, CNEX, EG

Airflow Range: 1,500 ~ 201,000 m³/h (882 ~ 118,235 CFM)

Total Pressure Range: 475～10,900 Pa (1.91～43.76 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Type: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certification: CE, ATEX, CNEX, EG

Airflow Range: 1,000 ~ 266,000 m³/h (588~156,471 CFM)

Total Pressure Range: 500 ~ 7,400 Pa (2.01~29.71 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Configurations: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certifications: AMCA, CNEX, ATEX, CE, EG

Airflow Range: 500 ~ 66,000 m³/h (294 ~38,824 CFM)

Total Pressure Range: 1,000 ~ 19,000 Pa (4.01 ~76.28 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Configurations: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certification: CE, ATEX, CNEX, EG

Airflow Range: 500 ~ 125,000 m³/h (294 ~ 73,529 CFM )

Total Pressure Range: 300～11,500 Pa (1.2 ~ 46.17 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Type: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion Resistant

Certification: CE, ATEX, CNEX, EG

Airflow Range: 1,000 ~ 144,000 m³/h (588 ~ 84,706 CFM)

Total Pressure Range: 1,000 ~ 17,000 Pa (4.01 ~ 68.25 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Type: Direct/ Belt/ Axial

Installation Methods: Base Mount

Applications: Industrial/ Explosion resistant. Suitable for extracting fume and vapour from environment

Certification: CE, CNEX, EG

Airflow range: 300～80,000 m3/h (176～47,059 CFM)

Static Pressure: 100～2,500 Pa (0.4 ~ 10 in.WG.)

Driven type: Direct drive

Temperature：-20~80℃

Airflow Range: 200 ~ 9,000 m³/h (118 ~5,294 CFM)

Total Pressure Range: 1,500 ~ 21,000 Pa (6.02 ~84.31 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Type: Direct/ Belt

Installation Methods: Base Mount

Applications: Industrial. Suitable for extracting fume and vapour from environment such as automobile, electronic, steel industries, etc.

Certification: CE

Airflow Range: 200 ~ 9,000 m³/h (118 ~5,294 CFM)

Total Pressure Range: 1,500 ~ 21,000 Pa (6.02 ~84.31 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Type: Direct/ Belt

Installation Methods: Base Mount

Applications: High Pressure/ Heavy Duty industry

Certification: CE

Airflow Range: 500 ~ 9,700 m³/h (294 ~ 5,706 CFM)

Total Pressure Range: 1,000 ~ 18,000 Pa (4.01 ~ 72.26 in.WG.)

Operating Temperature: -20 ~ 450 ℃

Drive Types: Direct/ Belt drive

Mounting Types: Base mounted

Applications: High pressure and heavy duty air supply and exhaust of gas containing dust or liquid impurities; suitable for steel, dust removal, painting and environmental protection industries.

Certification: CE

Airflow Range: 300 ~ 146,000 m³/h (176 ~ 85,882 CFM)

Total Pressure Range: 100 ~ 4,150 Pa (0.4 ~ 16.66 in.WG.)

Operating Temperature: -20 ~ 100 ℃

Drive Type: Belt

Installation Methods: Insertion

Applications: It can be directly inserted into the wall or other equipment. It is ideal for high temperature environment such as paint workshop where the paint job of the cars requires drying.

Airflow Range: 300 ~ 146,000 m³/h (176 ~ 85,882 CFM)

Total Pressure Range: 100 ~ 4,150 Pa (0.4 ~ 16.66 in.WG.)

Operating Temperature: -20 ~ 100 ℃

Drive Type: Belt

Installation Methods: Insertion

Applications: It can be directly inserted into the wall or other equipment. It is ideal for high temperature environment such as paint workshop where the paint job of the cars requires drying.

Airflow Range: 1,000 ~ 77,000 m³/h (588 ~ 45,294 CFM)

Air Pressure Range: 100～3,080 Pa (0.4～12.37 in.WG.)

Operating Temperature: -20 ~ 100 ℃

Drive Type: Belt / Direct Driven

Installation Methods: Base Mount

Applications： Industrial anti-corrosion/ Explosion Resistant
