Sidewall Exhaust Fan - WEX
Airflow Range: 400～29,000 m³/h (235～17,059 CFM)
Static Pressure Range: 40～300 Pa (0.16～1.2 in.WG.)
Drive Types: Direct drive
Mounting Types: Wall mounted
Applications: Sidewall air supply and exhaust / Explosion proof air supply and exhaust
For reference only. Please contact our sales rep for detailed performance fan curve. Thank you.
General type impeller with an external rotor motor.
Explosion proof aluminum impeller (aluminum is one of the non-ferrous metals. When combined with the use of an explosion proof motor, the fan will include AMCA 99 Type C Spark Resistant Construction)
Steel impeller for both general type and explosion proof applications (When used for explosion proof applications, the inlet bell is constructed of aluminum, a non-ferrous metal. Equipped with an explosion proof motor, the fan will include AMCA 99 Type C Spark Resistant Construction)
Stress Tested: High Strength Ensured for Durable Operation
- -- Computer aided stress analysis.
- -- Precisely positioned stiffeners through repeated tests to enhance the structure.
- -- Amplitude of blade ends greatly reduced.
- -- Deformation or cracking from long-term running prevented.
- Advanced Design of Forward Swept Blades
- -- Design optimized for optimal aerodynamic performance.
- -- Balance quality grade as high as G2.5 (AMCA).
- -- Streamlined and smooth blade curve to contact with the air more efficiently.
- -- Blades properly inclined to an angle to reduce turbulence effectively.
- -- Low sound ensured even with large airflow.
- Motor Located inside the Airstream + Lubrication-free Design: Suitable for Installation in High Places
- -- Small size, simple structure, light weight and reliable operation.
- -- Motor located inside the airstream: excellent heat dissipation performance to extend motor’s service life.
- -- Lubrication-free motor and maintenance-free fan, suitable for installation in high places.
- -- No belts, hence no need to ascend a height to change belts.
- More Reasonable Square Housing
- -- Square openings made on the concrete wall, brick wall and profiled sheet wall, which is much easier.
- -- Single layer of profiled sheet wall supported by horizontal beam to form a simple but reliable structure.
- Complete and Practical Accessories
- -- Standard accessories: 45 degree rain cover and stainless steel bird screen (for exhaust fans WEX); safety guard and stainless steel fasteners.
- -- Optional accessories: Gravity backdraft damper, epoxy coated housing and explosion proof structure.
- Fan Type
The sidewall axial supply/exhaust fans shall be equipped with steel or aluminum forward swept blades. Stiffeners shall be used on the blades for greater strength and reduced amplitude of blade ends. Motors and blades shall be statically and dynamically balanced to G2.5 as per AMCA (204-1996).
- Fan Housing
The housing shall be of square shape and constructed of galvanized steel (optional: cold rolled steel sheets finished with electrostatic epoxy coatings). Support structure for the motor shall be strong enough to prevent resonance vibrations during fan operation. Safety guard shall be mounted at the indoor part of the fan for safety concerns.
- Explosion Proof Structure (Optional)
The aluminum impeller and inlet bell are for explosion proof sidewall fan Model 250~550. The steel impeller and aluminum inlet bell are for explosion proof type Model 600~900. Explosion proof motors in flameproof enclosure Ex d IIC T4 and Ex d IIB T4 are used for general explosion proof type and compound explosion proof type respectively. As the inlet bell or impeller is constructed of aluminum, a non-ferrous metal, WEX fans include AMCA 99 Type C Spark Resistant Construction).
The external rotor motor shall be IP44 rated and internal rotor motor IP54 rated with Class F insulation. In order for the motor to get cooled, it shall be located inside the airstream. The wiring location is customized and the outgoing line shall be at least half a meter long.
A permanently fixed aluminum nameplate shall clearly display the fan number, product model and serial number (a unique ID for each fan) so that the parts used can be traceable by customers.
- Qualified Suppliers
INFINAIR or similar products supplied are designed based on Model WEX of INFINAIR.
